Pass-through warewashers

ACTIVE

High performance, without complications

2 models
  • Simple and user-friendly control.
  • Intuitive feedback using icons.
  • Dedicated cycles: selection of the ideal wash programme using icons. The duration of the cycle is adapted according to the type of item to be washed.
  • Electronic control panel with IP65 humidity protection.

Extremely easy to use

Simple and user-friendly control. Temp-ready light and automatic cycle start included.

Comparison ACTIVE

ACTIVE
AX-100AX-100BC
AX-100AX-100BC
Features
Basket dimensions500 x 500 mm500 x 500 mm
Useful height430 mm430 mm
Rinse pressure pump-yes
Wash tank capacity25 l25 l
Double skin--
Rinse temperature display-yes
Wash temperature display-yes
Cycles
Cycles33
Cycle duration120 / 180 / 210"120 / 180 / 210"
Production baskets / hour30 / 24 / 1730 / 24 / 17
Loading
Pump power1 Hp / 750 W1 Hp / 750 W
Tank2500 W2500 W
Boiler6000 W6000 W
Total loading6700 W6700 W
External dimensions (W x D x H)
External dimensions (W x D x H)648 x 756 x 1508 mm648 x 756 x 1508 mm
Height (open)2000 mm2000 mm
Data with water entry at 55ºC (recommended)

Pass-through warewashers

Glass- and dishwashers designed for comfortable operation thanks to front or side loading

Washing efficiency, reliability, hygiene, ergonomics and optimised consumption are the technical attributes that every professional needs. That's why Sammic is offering two ranges of dishwashers based on a common core.

Sani-Control guarantee

  • GUARANTEED DISINFECTION in compliance with standard DIN 10534.
  • "THERMAL LOCK" function: ensures that rinsing will be carried out at the ideal temperature to disinfect the dishes.

Deep drawn tanks

  • Ergonomic design with rounded corners to prevent the accumulation of dirt and facilitate cleaning.
  • Compact tank volume (50% water saving compared to the previous range).

Hydroblade™ washing arms

  • Redesigned nozzles for greater washing performance.
  • The "monoblock" design delivers durability and resistance to impacts.
  • 30% savings in water consumption during rinsing compared to the previous range.

3-stage filter system: surface, tank and extraction

  • Keeps the washing water in optimal conditions to maintain constant washing performance.

Designed to last

  • "Flow" opening mechanism: allows the hood to be raised with less effort.
  • High load capacity 43 cm: suitable for GN 1/1 and Euronorm 1/1.
  • Stainless steel surface filters for greater stability and resistance during intensive use.

You will never WASH ALONE

  • Tech Services: our team of technicians will help you so that your machine is always ready for use.
  • Design Services: tell us what your needs are and we will advise you.
  • 60 years of experience and know-how at your disposal.

More images

Access our albums

Compact tank volume

Maximum efficiency.

Hydroblade™ washing arms

Water savings, washing efficiency, strength and durability.

"Easy-on" surface filters

Extremely easy assembly and disassembly.

Large capacity

430 mm door clearance.

Comparison

ACTIVEULTRA
AX-100AX-100BCUX-100UX-120UX-120BCUX-120VUX-120CVUX-120UX-120V (VENTLESS)UX-130BC DDUX-130BCD DDUX-130BC ISO DDUX-130BCV ISO DDUX-130BCDV ISO DDUX-150SBC DDUX-150SBCV
AX-100AX-100BCUX-100UX-120UX-120BCUX-120VUX-120CVUX-120UX-120V (VENTLESS)UX-130BC DDUX-130BCD DDUX-130BC ISO DDUX-130BCV ISO DDUX-130BCDV ISO DDUX-150SBC DDUX-150SBCV
Features
Basket dimensions500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm500 x 500 mm600 x 500 mm600 x 500 mm
Useful height430 mm430 mm430 mm430 mm430 mm430 mm430 mm430 mm430 mm430 mm430 mm430 mm440 mm430 mm430 mm430 mm
Rinse pressure pump-yes--yes-yes--yesyesyesyesyesyesyes
Wash tank capacity25 l25 l25 l25 l25 l85 l25 l25 l25 l25 l25 l25 l23 l25 l25 l25 l
Double skin----opt.-yesyes--yesyesyesyesyes
Rinse temperature display-yesyesyesyesyesyesyesyesyesyesyesyesyesyesyes
Wash temperature display-yesyesyesyesyesyesyesyesyesyesyesyesyesyesyes
Cycles
Cycles3366666666666666
Cycle duration120 / 180 / 210"120 / 180 / 210"60 / 90 / 100 / 150 / 210"60 / 90 / 100 / 150 / 210"60 / 90 / 100 / 150 / 210"60 / 90 / 100 / 150 / 210"60 / 90 / 100 / 150 / 210"60/90/100/150/210"60/90/100/150/210"60 / 90 / 100 / 150 / 210"60/90/100/150/210"60/90/100/150/210"60/90/100/150/210"60/90/100/150/210"60 / 90 / 100 / 150 / 210"60 / 90 / 100 / 150 /210"
Production baskets / hour30 / 24 / 1730 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760/40/36/24/1760/40/36/24/1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 1760 / 40 / 36 / 24 / 17
Loading
Pump power1 Hp / 750 W1 Hp / 750 W1 Hp / 750 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.3 Hp / 1000 W1.33 Hp / 1000 W2 Hp / 1500 W2 Hp / 1500 W
Tank2500 W2500 W2500 W2500 W3000 W3000 W3000 W2500 W3000 W3000 W3000 W
Boiler6000 W6000 W7500 W7500 / 9000 W9000 W9000 W9000 W9000 W9000 W9000 W9000 W
Total loading6700 W6700 W8250 W8500 / 10000 W8500 / 10000 W8500 / 10000 W8500 / 10000 W8500 / 10000 W8500 / 10000 W10000 W10000 W10000 W9000 W10000 W10500 W10500 W
External dimensions (W x D x H)
External dimensions (W x D x H)648 x 756 x 1508 mm648 x 756 x 1508 mm648 x 756 x 1510 mm650 x 755 x 1525 mm648 x 756 x 1508 mm650 x 755 x 2035 mm650 x 755 x 2035 mm650 x 755 x 1520 mm650 x 755 x 2035 mm650 x 755 x 1600 mm650 x 755 x 1525 mm650 x 755 x 1525 mm640 x 756 x 1468 mm640 x 756 x 2035 mm730 x 760 x 1572 mm730 x 760 x 1572 mm
Height (open)2000 mm2000 mm2000 mm2000 mm2000 mm2035 mm2035 mm2000 mm2035 mm2070 mm2070 mm2070 mm1920 mm2035 mm2080 mm2080 mm
Data with water entry at 55ºC (recommended)
